Grade 208
Aqualab cellulose extraction thimbles are made of noble cellulose fibers and cotton linters that are completely free from impurities. Using the most efficient and innovative technology we obtain a mold made of a single completely homogeneous piece.
Max usage temp. 100 ºC
Applications
- Determination by extraction of the content of free lipids in food.
- Sulfur extraction in gaseous masses.
- Dust dimensions in air or industrial gases.
- Soxhlet extraction for determination of fats, lipids, additives or pesticides in the food industry
- Soxhlet extraction for determination of resin components in tar (road construction)
- Soxhlet extraction of oil and softeners
- Extraction of oil and lubricants in slurry and waste water
- Extraction of mineral oils in rocks
- Extraction of polychlorinated biphenyl (PCB) in soil and slurry, e.g. dioxin
- Extraction of monomeric components
in plastic materials and rubber
Technical Specifications
| Grade | Material | Nominal rating (µ) | Thickness (mm) | Pressure drop (Kpa at 5L/min) | Collection efficiency (% 0.3µm DOP) | Max. Operating temp (ºC) | Heating loss rate (%) |
| 208 | Cellulose | 8 | 1.2 | 0.25 | 0.25 | 120 | – |
Standard dimensions / Information for orders
| Dimension (mm)Inner diameter x lenght | Code | Units/box |
| Cellulose extraction thimble 10 x 50 | CT1050 | 25 |
| Cellulose extraction thimble 16 X 100 | CT16100 | 25 |
| Cellulose extraction thimble 19 X 90 | CT1990 | 25 |
| Cellulose extraction thimble 20 X 45 | CT2045 | 25 |
| Cellulose extraction thimble 22 X 45 | CT2245 | 25 |
| Cellulose extraction thimble 22 X 50 | CT2250 | 25 |
| Cellulose extraction thimble 22 X 60 | CT2260 | 25 |
| Cellulose extraction thimble 22 X 80 | CT2280 | 25 |
| Cellulose extraction thimble 22 X 100 | CT22100 | 25 |
| Cellulose extraction thimble 23 X 80 | CT2380 | 25 |
| Cellulose extraction thimble 24 X 110 | CT24110 | 25 |
| Cellulose extraction thimble 25 X 65 | CT2565 | 25 |
| Cellulose extraction thimble 25 X 70 | CT2570 | 25 |
| Cellulose extraction thimble 25 X 80 | CT2580 | 25 |
| Cellulose extraction thimble 25 X 100 | CT25100 | 25 |
| Cellulose extraction thimble 26 X 60 | CT2660 | 25 |
| Cellulose extraction thimble 26 X 60*Special size for Tecator extractors | CT2660 | 25 |
| Cellulose extraction thimble 27 X 80 | CT2780 | 25 |
| Cellulose extraction thimble 27 X 100 | CT27100 | 25 |
| Cellulose extraction thimble 28 X 80 | CT2880 | 25 |
| Cellulose extraction thimble 28 X 100 | CT28100 | 25 |
| Cellulose extraction thimble 30 X 60 | CT3060 | 25 |
| Cellulose extraction thimble 30 X 77 | CT3077 | 25 |
| Cellulose extraction thimble 30 X 80 | CT3080 | 25 |
| Cellulose extraction thimble 30 X 100 | CT30100 | 25 |
| Cellulose extraction thimble 33 X 80 | CT3380 | 25 |
| Cellulose extraction thimble 33 X 80*Special size for Tecator extractors | CT3380 | 25 |
| Cellulose extraction thimble 33 X 94 | CT3394 | 25 |
| Cellulose extraction thimble 33 X 100 | CT33100 | 25 |
| Cellulose extraction thimble 33 X 118 | CT33118 | 25 |
| Cellulose extraction thimble 34 X 130 | CT34130 | 25 |
| Cellulose extraction thimble 35 X 50 | CT3550 | 25 |
| Cellulose extraction thimble 35 X 80 | CT3580 | 25 |
| Cellulose extraction thimble 35 X 100 | CT35100 | 25 |
| Cellulose extraction thimble 35 X 110 | CT35110 | 25 |
| Cellulose extraction thimble 35 X 150 | CT35150 | 25 |
| Cellulose extraction thimble 40 X 100 | CT40100 | 25 |
| Cellulose extraction thimble 41 X 123 | CT41123 | 25 |
| Cellulose extraction thimble 43 X 123 | CT43123 | 25 |
| Cellulose extraction thimble 46 X 140 | CT46140 | 25 |
| Cellulose extraction thimble 48 X 150 | CT48150 | 25 |
| Cellulose extraction thimble 50 X 150 | CT50150 | 25 |
| Cellulose extraction thimble 60 X 150 | CT60150 | 25 |
| Cellulose extraction thimble 70 X 180 | CT70180 | 25 |
| Cellulose extraction thimble 80 X 200 | CT80200 | 25 |
| Cellulose extraction thimble 90 X 220 | CT92200 | 25 |
| Cellulose extraction thimble 90 X 250 | CT90250 | 25 |
